Monitor CAMOS RAV-MO7 7 palcový

CARGUARD REAR ANGEL VIEW RAV-MO-7, 7-inch monitor, 800×480 pixels, 2 camera inputs (analogue up to 700TVL), 9-32V for analogue PAL and NTSC cameras. The extremely robust and high-quality RAV-MO 7 monitor with outstanding image quality enables you to equip your vehicle with a fully-fledged premium reversing video system in conjunction with the reversing cameras from Car Guard Systems. 2 camera inputs ensure that you have everything in view at all times and that safety is guaranteed. The 2 trigger inputs can be used to switch on the cameras via various triggers, whereby reversing view always takes priority.
Thanks to its built-in loudspeaker, this monitor can play back the sounds around the camera in the driver’s cab, e.g. during instruction.
Device information:
Monitor with 2 camera inputs
Resolution: 384,600 pixels
Operating voltage 9 32 V DC
For all analogue and digital PAL and NTSC cameras (automatic detection)
Picture format: 16:9
Rubberised, haptically very pleasant monitor housing
2 inputs for automatically switching on the monitor, e.g. reversing lights, indicators, implements or dashboard switch (reversing light input has priority)
ACC-Time: Delay holding time of the reversing camera image after switching off the signal on the reversing light cable. Setting options: Off, 1 15 s
Cameras can be mirrored for front/rear use or left/right mounting, display of the left or right mirror image can be selected in each channel
OSD setting options for brightness, contrast, colour saturation and volume
Optionally available adapters for standard pre-installed camera cables from brands such as Orlaco, Dometic, Brigade, Axion, Mekra and Car Guard Systems (including older models)
Product dimensions and weight:
Dimensions: H: 195mm/ W: 114mm/ D: 55mm
Weight: 295g
Packaging weight: 1100g
Packaging dimensions: Length: 305 mm/ Width: 202 mm/ Height: 90 mm
Certificates:
ROHS
CE
E-Mark
Scope of delivery: including monitor, connection cable harness, remote control, monitor base made of powder-coated sheet steel and installation and operating instructions
